Flash Sales
100NF50V 0805 SMD CAPACITOR (packet of 100)
100NF50V 0805 SMD CAPACITOR - These MLCCs consist of a conducting material and electrodes. To manufacture a chip-type SMT and achieve miniaturization, high density, and high efficiency, ceramic condensers are used. These MLCCs are made from high-quality dielectric material and provide products with high electrical precision, stability and reliability.
100nF 0805 Surface Mount Multilayer Ceramic Capacitor is a rectangular block of ceramic dielectric in which a number of interleaved metal electrodes are contained.
2SA1943 PNP Power Amplifier Transistor
The 2SA1943 is a high-power PNP Power transistor manufactured by Toshiba. It has a collector continuous current of 15A and a Collector-Emitter voltage of 230V. The base current is about 1.5A and the Emitter base voltage is 5V.
Due to its high current gain and collector current, it is very commonly used in?High power audio circuits or AF amplifiers. Recommended for 150-W high-fidelity audio frequency amplifier output stage. The transistor is popularly used in push-pull audio circuits along with this NPN Equivalent?2SC5200 NPN Transistor.
2SC5200 NPN
2SC5200?NPN Power Amplifier Transistor 230V?with 1.5V Base and 15V Collector Current is type of bipolar transistor consisting of a layer of P-doped semiconductor (base) between two N-doped layers. A small current entering the base is amplified to produce a large collector and emitter current.
They are used in Mobile Phones, Industrial controls, televisions and Flip-flops, and High-Frequency Application Such as Radio Frequency Audio circuits.80C51 MICROCONTROLLER
ADS1230IPWR – 20 Bit Analog to Digital Converter For Bridge Sensors
ADS1230IPWR - 20-Bit, 80SPS, 1-Ch Delta-Sigma ADC for Resistive Bridge Sensors & Weigh Scales
The ADS1230 is a 20-bit precision analog-to-digital converter (ADC). The ADS1230 provides a full front-end system for bridge application areas such as weigh scales, strain gauges, and pressure sensors thanks to an inbuilt low-noise programmable gain amplifier (PGA), onboard oscillator, and precision 20-bit delta-sigma ADC. The low-noise PGA has a gain of 64 or 128, allowing for a full-scale differential input of 39mV or 19.5mV. The delta-sigma ADC has an effective resolution of 20 bits and is made up of a 3rd order modulator and a 4th order digital filter. APPLICATIONS- Weigh Scales
- Strain Gauges
- Pressure Sensors
- Industrial Process Control
ADS1232IPWR -24-Bit, Delta-Sigma ADCs for Bridge Sensors
ADS1232IPWR is 24-bit precision analog-to-digital converter (ADCs). The ADS123x provides a full front-end solution for bridge sensor applications such as weigh scales, strain gauges, and pressure sensors thanks to its low-noise programmable gain amplifier (PGA), precision delta-sigma ADC, and internal oscillator. A differential input multiplexer (MUX) can receive two (ADS1232) or four (ADS1234) differential inputs. The ADS1232 also has a temperature sensor to monitor the outside temperature. The low-noise PGA supports a full scale differential input of 2.5 V, 1.25 V, 39 mV, or 19.5 mV and has a selectable gain of 1, 2, 64, or 128. The delta-sigma ADC has a maximum effective resolution of 23.5 bits and two data rates: 10 SPS (with 50-Hz and 60-Hz rejection) and 80 SPS.? directly connected to the MSP430 and other microcontrollers.
AT89S52 MICROCONTROLLER
Atmel AT89S52 Microcontroller high-performance CMOS 8-bit microcontroller
The Atmel AT89S52 Microcontroller or commonly known as AT89S52 is a low-power, high-performance CMOS 8-bit microcontroller with 8K bytes of in-system programmable Flash memory. The device is manufactured using Atmel?s high-density nonvolatile memory technology and is compatible with the industry-standard 80C51 instruction set and pinout. The on-chip Flash allows the program memory to be reprogrammed in-system or by a conventional nonvolatile memory programmer. By combining a versatile 8-bit CPU with in-system programmable Flash on a monolithic chip, the Atmel AT89S52 is a powerful microcontroller which provides a highly-flexible and cost-effective solution to many embedded control applications. Program Any IC, Micro-Controller | AT89S52, AT89S51, AT89C51,AT89C52 | Universal ISP Programmer :https://www.youtube.com/watch?v=Zhsktt0S1Fo
ATMEGA128A-AU
ATMEGA128A-AU 8-bit Microcontrollers
The ATMEGA128A-AU is a high-performance, low-power 8-bit AVR RISC-based Microcontroller combines 128kb flash memory with read-while-write capabilities, 4kb EEPROM, 53 general purpose I/O lines, 32 general purpose working registers, real time counter, four flexible timer/counters with compare modes and PWM, two USARTs , a byte oriented Two-wire serial interface, an 8-channel/10-bit A/D converter with optional differential input stage with programmable gain, programmable watchdog timer with internal oscillator, SPI serial port, a JTAG (IEEE 1149.1 compliant) test interface for accessing the on-chip debugging and programming and six software selectable power saving modes. The device operates between 2.7 to 5.5V. By executing powerful instructions in a single clock cycle, the device achieves throughputs approaching 1 MIPS per MHz, balancing power consumption and processing speed. Manufacturer: Microchip Technology Manufacturer Product Number: ATMEGA128A-AU Description: MCU 8BIT 128KB FLASH 64TQFP Detailed Description: AVR AVR? ATmega Microcontroller IC 8-Bit 16MHz 128KB (64K x 16) FLASH 64-TQFP (14x14) ATMEGA128A-AU Datasheet:
ATMEGA16A-AU Microcontroller
The ATmega16A-AU is a low-power CMOS 8-bit microcontroller based on the Atmel AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega16A achieves throughputs approaching 1MIPS per MHz allowing the system designer to optimize power consumption versus processing speed.
ATMEGA16A-AU Microcontroller - Specs
Manufacturer - MICROCHIP (ATMEL)
Part Number - ATMEGA16A-AU
Type of integrated circuit - AVR microcontroller
Description - 8 Bit Microcontrollers ? MCU
Number of Pins - 44
Datasheet -?ATMEGA16A-AU Datasheet
ATMEGA16A-MU Microcontroller
This is Microchip ATMEGA16A-MU, 8bit AVR Microcontroller. The ATmega16A is a low-power CMOS 8-bit microcontroller based on the Atmel AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega16A achieves throughputs approaching 1MIPS per MHz allowing the system designer to optimize power consumption versus processing speed.
ATMEGA16A-MU Microcontroller - Specs
Manufacturer - MICROCHIP (ATMEL)
Part Number - ATMEGA16A-MU
Type of integrated circuit - AVR microcontroller
Description - 8 Bit Microcontrollers ? MCU
Number of Pins - 44
Datasheet - ATMEGA16A-MU Datasheet
ATMEGA16A-PU Microcontroller
ATMEGA16A-PU Microcontroller - The ATmega16 is a low-power CMOS 8-bit microcontroller based on the AVR-enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATmega16 achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed. This is Microchip ATMEGA16A-PU, 8bit AVR Microcontroller, AVR ATmega Family ATmega8 Series Microcontrollers. Buy AVR ATmega Family ATmega8 Series Microcontrollers online in Mumbai India.
ATMEGA16A-PU Microcontroller - Specs
Manufacturer - MICROCHIP (ATMEL)
Part Number - ATMEGA16A-PU
Type of integrated circuit - AVR microcontroller
Description - 8 Bit Microcontrollers ? MCU
Number of Pins - 44
Datasheet - ATMEGA16A-PU Datasheet
