LNK6666E
LNK6666E Power Integrations LinkSwitch?-HP Off-Line Switcher family of flyback power supply ICs incorporate a primary side regulated (PSR) controller and high-voltage power MOSFET in a single package. The IC family includes devices optimized for constant voltage (CV) operation at power ranges from 9W to 90W. Power Integrations LinkSwitch-HP IC controller features +/-5% CV accuracy, selectable current limit, programmable latching or hysteretic OVP, UVP and OTP, improved overload power compensation over the line, fast AC reset, and programmable shutdown delay time. These devices include a K package and an eSOP-12B low-profile surface-mount package for ultra-slim designs.
Mfr. No: LNK6666E
Mfr.:Power Integrations
Package/Case: eSIP-7C
Description: AC/DC Converters Off-Line Switcher IC PSR LinkSwitch HP
Datasheet: LNK6666E Datasheet (PDF)
LP5907MFX-3.0/NOPB
Features of LP5907MFX-3.0
? 2.2 to 5.5 volts of input voltage
? 1.2 to 4.5 volts in the output voltage range
? Stable with ceramic input and output capacitors rated at 1 F
? No need for a noise bypass capacitor
? Location of the remote output capacitor
? Protection from thermal overload and short circuit
? Operating junction temperature range of -40?C to 125?C
? Low noise output voltage: 6.5 VRMS
? PSRR at 1 kHz: 82 dB
? Tolerance for output voltage: 2%
? Exceptionally low IQ: 12 A
? Minimal dropout (120 mV)
Applications of LP5907MFX-3.0
- Smartphones
- ?Tablets
- ?Communications equipment
- Digital still cameras
- Factory automation
LPV358MM/NOPB
Part Number:LPV358MM/NOPB
Mfr.:Texas Instruments
Description: Operational Amplifiers - Op Amps Gen Purp Low Vtg Low Pwr RRO Op Amp
LPV321-N Single, LPV358-N Dual, and LPV324-N Quad General-Purpose, Low Voltage,Low Power, Rail-to-Rail Output Operational Amplifiers.
The LPV358MM are low power (9-?A per channel at 5 V) versions of the LMV3xx op amps. This is another addition to the LMV family of commodity op amps. The LPV3xx-N are the most cost effective solutions for the applications where low voltage, low power operation, space saving and low price are needed.
The LPV358MM have rail-to-rail output swing capability and the input common-mode voltage range includes ground. They all exhibit excellent speed-power ratio, achieving 152 kHz of bandwidth with a supply currentof only 9 ?A.
LPV358MM/NOPB Datasheet
M24128-DRDW8TP/K
Features? of M24128-DRD
- Support for all I2C bus modes? 1 MHz/ 400 kHz/ 100 kHz
- Memory bank- An EEPROM with 128 Kbits (16 Kbytes)
- Page Size in Bytes: 64
- In addition Make a locked page.
- Wider range of temperatures and voltages?40 to 105 degrees Celsius; 1.7 to 5.5 volts
- Schmitt trigger inputs are used to filter noise.
- Cycle time for short writes- Byte Write in 4 milliseconds- Page Write in 4 milliseconds
- Express cycling stamina. -4,000,000 Write Cycles at 25 ?C, - 1,2,000,000 Write cycles at 85 ?C & ? 900 k Cycles of writing at 105 ?C
- Data storage- at 105 ?C for more than 50 years., 200 yr at 55 ?C
- ESD Defense (Human Body Model)? 4000 V
- Packing is- Halogen-free and RoHS compliant
- SMD/SMT mounting style
- Case/Package: TSSOP-8
- Interface types: I2C and 2-Wire
- Size of Memory: 128 kbit
- Arrangement: 16 k x 8
- Minimum Supply Voltage: 1.7 V
- Maximum Supply Voltage: 5.5 V
- 40 C for the minimum operating temperature
- 105 C is the maximum operating temperature.
- 1 MHz is the maximum clock frequency.
- Time to Access: 450 ns
- Retention of Data: 200 Years
- Maximum Supply Current: 2 mA
- The M24128-DRD series
- mandatory requirement: AEC-Q100
- Packaging: Cut Tape and Reel
- Maximum Active Read Current: 2 mA
- STMicroelectronics is a brand.
- 2 mA is the operating supply current.
- Voltage Range for Operating Supply: 1.8 to 5.5 V
- Type of Product: EEPROM
M25P40-VMN6TPB
Features of M25P40-VMN6TPB?
- ?4 Mbit of Flash memory
- ?2.3 V to 3.6 V single supply voltage
- ?SPI bus compatible serial interface
- ?75 MHz clock rate (maximum)
- ?Page Program (up to 256 bytes) in 0.8 ms (typical)
- ?Sector Erase (512 Kbit) in 0.6 s (typical)
- ?Bulk Erase (4 Mbit) in 4.5 s (typical)
- ?Deep Power-down mode 1 ?A (typical)
- ?Hardware Write Protection: protected area size defined by three non-volatile bits (BP0, BP1 and BP2)
- ?Electronic signatures ? JEDEC standard two-byte signature (2013h) ? Unique ID code (UID) with 16 bytes read only, available upon customer request ? RES instruction, one-byte, signature (12h), for backward compatibility
- ?Packages ? RoHS compliant
- ?Automotive grade parts available
- Memory Size -
- Supply Voltage - Min: 2.3 V
- Supply Voltage - Max: 3.6 V
- Active Read Current - Max: 8 mA
- Interface Type: SPI
- Maximum Clock Frequency: 75 MHz
- Organisation: 512 k x 8
- Data Bus Width: 8 bit
- Timing Type: Synchronous
- Minimum Operating Temperature: - 40 C
- Maximum Operating Temperature: + 85 C
- Packaging: Reel / Cut Tape
- Memory Type: NOR
- Product Type: NOR Flash
- Speed: 75 MHz
MAX186 Low Power 8-Channel Serial 12-Bit ADC Maxim DIP-20 Package
MAX232 Dual Driver/Receiver IC DIP-16 Package
MAX232E is from the family of RS-232 and V.28 transceivers with high ?15kV ESD HBM protection and integrated charge pump circuitry for single 5V supply operation. The various combinations of features are outlined in the Selector Guide.
Part No: MAX232E
MAX232E Datasheet
MAX232 TTL to RS232 IC
MAX232 is a communication IC. It is used to convert TTL Signals to RS232 Signal and vice versa.?MAX232?provides RS-232 voltage level outputs (approx. ? 7.5 V) from a single 5 V supply via on-chip charge pumps and external capacitors. This makes it useful for implementing RS-232 in devices that otherwise do not need any voltages outside the 0 V to 5 V range, as power supply design does not need to be made more complicated just for driving the RS-232 in this case.
The receivers reduce RS-232 inputs (which may be as high as ? 25 V), to standard 5 V TTL levels. These receivers have a typical threshold of 1.3 V, and a typical hysteresis of 0.5 V.
MAX3232 RS-232 Line Driver
The?MAX3232 device?consists of two line drivers, two line receivers, and a dual charge-pump circuit with ?15-kV ESD protection pin to pin (serial-port connection pins, including GND). The device meets the requirements of TIA/EIA-232-F and provides the electrical interface between an asynchronous communication controller and the serial-port connector.? The devices operate at data signaling rates up to 250 kbit/s and a maximum of 30-V/?s driver output slew rate.
MAX3232-SMD RS-232 Line Driver
MAX3232 device?consists of two line drivers, two line receivers, and a dual charge-pump circuit with ?15-kV ESD protection pin to pin (serial-port connection pins, including GND). The device meets the requirements of TIA/EIA-232-F and provides the electrical interface between an asynchronous communication controller and the serial-port connector. The charge pump and four small external capacitors allow operation from a single 3-V to 5.5-V supply. The devices operate at data signalling rates up to 250 kbit/s and a maximum of 30-V/?s driver output slew rate.
