100nH 1.7A Air-Core Inductor
Product Summary/Description
This is a 1.7A 100nH Air-Core Inductor. Air-Core RF Inductors, a type of wound air core inductor, are excellent for RF circuits, broadband I/O filtering, frequency selection, and impedance matching. With greater Q and superior power handling capacities, air core inductors outperform solid-core inductors. Construction with an air core
Features of Products
Excellent SRF due to high Q and current.
Specifications:
Inductance?100nH
Tolerance (percentage) 5
DCR (m) DC Resistance at 20?C 12.3
The current rating (A) is 1.7.
SMD/SMT mounting type
4.83 in.
3.81 mm width
4.2 mm in height
Each weighs 0.5 grams.
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
33nH 3A Air-Core Inductor
Product Description/Summary
A 33nH 3A Air-Core Inductor is what this is. Air-Core RF Inductors, a type of wound air core inductor, are excellent for RF circuits, broadband I/O filtering, frequency selection, and impedance matching. With greater Q and superior current handling capabilities, air core inductors outperform solid-core inductors.
Product Features
Construction with an air core
Excellent SRF due to high Q and current.
Specifications of the Product:
Inductance? 33nH
Tolerance (percentage) 5
DCR (m) DC Resistance at 20?C 4.8
Current Grade (A) 3
2.5GHz (Hertz)
SMD/SMT mounting type
4.83 mm in length
3.81 mm width
4.2 mm in height
0.5 gram?in weight
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
33uH 430mA SMD Coupled Inductor
Description/Summary of the Product
This is a 430mA 33uH 20 percent 0.4475 Ohm Coupled Inductor. It is a surface mount SMD coupled inductor with a reduced DCR and a high rated current. These are lead-free and RoHS-compliant items. These inductors are commonly found in buck converters, laptops, screens, network connection equipment, and other electronic devices.
Features of the Product:
Buzz noise is reduced to extremely low levels because to the magnetic-resin insulated structure.
The metallization of the ferrite core leads in high shock resistance and long-term endurance.
The use of a closed magnetic circuit decreases leaking flux and electro magnetic interference (EMI)
30% greater current rating than comparable conventional inductors
Take up less PCB space and save more energy.
Additional Information of the Product:
Inductance? is??33uH
Tolerance (20%) 20
SMD/SMT mounting type
At 20?C, the DC Resistance (DCR) (m) is 0.4475.
430mA is the current rating (A).
5 mm in length
5 mm in width
3 mm in height
0.2 gram?in weight
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
4.7uH 760mA SMD Coupled Inductor (Packet of 50)
Description/Summary of The? Product
This is a Coupled Inductor with a 4.7uH 20 percent 0.503 Ohm 760 mA rating. It is a surface mount SMD coupled inductor with a low DCR and a high rated current. These are lead-free and RoHS-compliant items. These inductors are commonly found in buck converters, laptops, screens, network connection equipment, and other electronic devices.
Features of the Product:
Buzz noise is reduced to extremely low levels because to the magnetic-resin insulated structure.
The metallization of the ferrite core leads in high shock resistance and long-term endurance.
The use of a closed magnetic circuit decreases leaking flux and electro magnetic interference (EMI)
30% greater current rating than comparable conventional inductors
Take up fewer PCB space and save more energy.
Additional Information for the Product:
The inductance is 4.7uH.
Tolerance (20%) 20
SMD/SMT mounting type
At 20?C, the DC Resistance (DCR)(m) is 0.503.
760mA is the current rating (A).
3 mm in length
3 mm in width
1.4 mm in height
Each weighs 0.5 grams.
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
470uH 250mA SMD Coupled Inductor (Packet of 100)
Summary/Description of the Product:
This is an LPD6235-474MRB 470uH 250mA Coupled Inductor from COILCRAFT. It is a surface mount SMD coupled inductor with a low DCR and a high rated current. These are lead-free and RoHS-compliant items. These inductors are commonly found in buck converters, laptops, screens, network connection equipment, and other electronic devices.
Special Features of the Product :
Buzz noise is reduced to extremely low levels because to the magnetic-resin insulated structure.
The metallization of the ferrite core leads in high shock resistance and long-term endurance.
The use of a closed magnetic circuit decreases leakage flux and electro magnetic interference (EMI)
30% greater current rating than comparable conventional inductors
Take up less PCB space and save more energy.
Additional Information of the product:
The inductance is 470uH.
Tolerance (20%) 20
SMD mount
At 20?C, the DC Resistance (DCR) (m) is 1.75.
250m A Current Rating
6 mm in length
6 mm in width
3.5 mm in height
Each weighs 0.5 gram.
* Item photographs are intended for illustration reasons and may fluctuate from the original product.
47nH 3A Air-Core Inductor
Product Summary/Description
A 47nH 3A Air-Core Inductor is what this is. Air-Core RF Inductors, a type of wound air core inductor, are excellent for RF circuits, broadband I/O filtering, frequency selection, and impedance matching. With greater Q and superior current handling capabilities, air core inductors outperform solid-core inductors.
Features of Product
Construction with an air core
Excellent SRF due to high Q and current.
Extra Information on Product:
Inductance
47nH
Tolerance (percentage) 5
DCR (m) DC Resistance at 20?C 5.6
Current Grade (A) 3
SMD/SMT Mounting
4.83 mm in length
3.81 (millimeters) width
4.2 mm in height
0.5 gram?in weight
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
68uH 890mA SMD Coupled Inductor (Packet of 100)
Description/Summary of the Product:
This is a 890 mA Coupled Inductor with a 68uH 20 percent 0.507 Ohm resistance. It is a surface mount SMD coupled inductor with a low DCR and a high rated current. These are lead-free and RoHS-compliant items. These inductors are commonly found in buck converters, laptops, screens, network connection equipment, and other electronic devices.
Features:
Buzz noise is reduced to extremely low levels because to the magnetic-resin insulated structure.
The metallization of the ferrite core leads in high shock resistance and long-term endurance.
The use of a closed magnetic circuit decreases leakage flux and electro magnetic interference (EMI)
30% greater current rating than comparable conventional inductors
Take up minimal PCB space and conserve?more energy.
Additional Information about the Product:
The inductance is 68uH.
Tolerance (20%) 20
SMD mounting type
At 20?C, the DC Resistance (DCR) (m) is 0.507.
Current Rating (A): 890m
7.6 mm in length
7.6 mm in width
3.4 mm in height
0.8 gram?in weight
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
8D43 10uH (100) 2A SMD (Packet of 50)
Product Description
A surface mount device is a 10uH 2A SMD power inductor. The core is a ferrite drum around which a wire is coiled. This inductor is RoHS compliant and contains a magnetic shield. The power inductor has a humidity vulnerability rating of 1, indicating that it is very resistant to moisture.
This kind of inductor features surface mounting pads.
Applications:
Ideally utilized as DC-DC converter inductors in mobile phones, MP3, PDAs, HDDs, DSC/DVCs, and other devices.
Product Features
Ferrite drum center composition is one of the features.
The size is little.
Magnetic protection.
Resistant against moisture.
Surface installation.
Compliant with RoHS.
Specifications:
10uH inductance
SMD/SMT mounting type
Ferrite Core Material
30 Tolerance (percentage)
DCR (m) DC Resistance at 20?C 36
4 is the current rating.
100 kHz frequency
Temperature range of operation (?C) -40 to 100
9 mm in length
8 mm in width
4.2 mm in height
Weight (gm)? 1 (approx.)
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
8D43 330uH (331) 2A SMD (Packet of 50)
Summary of the Product
A surface mount device is a 330uH 2A SMD power inductor. The core is a ferrite drum around which a wire is coiled. This inductor is RoHS compliant and contains a magnetic shield. The power inductor has a dampness tolerance rating of 1, indicating that it is very resistant to moisture.
This type of inductor features surface mounting pads.
Applications of the Product
Ideally utilized as DC-DC converter inductors in mobile phones, MP3, PDAs, HDDs, DSC/DVCs, and other devices.
Features of the Product
Ferrite drum center composition is one of the features.
The size is little.
Magnetic protection.
Resistant against moisture.
Surface installation.
Compliant with RoHS.
Specifications:
Inductance (uH) 330
SMD/SMT mounting type
Ferrite Core Material
30 Tolerance (percentage)
DCR (m) DC Resistance at 20?C 360
1.3 is the current rating.
100 kHz frequency
Temperature range of operation (?C) -40 to 100
9 mm in length
8 mm in width
4.2 mm in height
1 gram weight (approx.)
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
8D43 47uH (470) 2A SMD (Packet of 50)
Summary/Description of the Product
A surface mount device is a 47uH 2A SMD power inductor. The core is a ferrite drum around which a wire is coiled. This inductor is RoHS compliant and contains a magnetic shield. The power inductor has a humidity tolerance rating of 1, indicating that it is very resistant to moisture.
This type of inductor features surface mounting pads.
Applications of The Product:
Ideally utilised as DC-DC converter inductors in mobile phones, MP3, PDAs, HDDs, DSC/DVCs, and other devices.
Features of the Product
Ferrite drum center composition is one of the features.
The size is little.
Magnetic protection.
Resistant against moisture.
Surface installation.
Compliant with RoHS.
Specifications:
Inductance (uH) 47
SMD/SMT mounting type
Ferrite Core Material
30 Tolerance (percentage)
At 20?C, the DC Resistance (DCR) (m) is 150.
1.8 is the current rating.
100 kHz frequency
Temperature range of operation (?C) -40 to 100
9 mm in length
8 mm in width
4.2 mm in height
1 gram?weight (approx.)
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
CD43 3.3uH (3R3) 1A SMD (Packet of 20)
Product Description/Summary
A surface mount device is the CD43 3.3uH 1A SMD Power Inductor. The core is a ferrite drum around which a wire is coiled. This inductor is RoHS compliant and contains a magnetic shield. The power inductor has a moisture sensitivity rating of 1, indicating that it is very resistant to moisture. This type of inductor features surface mounting pads.
Applications of the product:
Ideally utilized as DC-DC converter inductors in mobile phones, MP3, PDAs, HDDs, DSC/DVCs, and other electronic devices.
Features of the Product
Ferrite drum center composition is one of the features.
The size is little.
Magnetic protection.
Resistant against moisture.
Surface installation.
Compliant with RoHS.
Specifications:
Inductance(uH) 3.3
SMD/SMT mounting type
Ferrite Core Material
Tolerance (20%) 20
2 (mA) Current Rating
At 20?C, DC Resistance (DCR)(m) = 86.2
7.96 MHz frequency
Temperature range (?C): -40 to 100
4.3 mm in length
4 mm width
3.2 mm in height
1 gram (gm) (approx.)
* Item photographs are intended for illustration reasons and may fluctuate from the actual product.
CD43 4.7uH (4R7) 1A SMD (Packet of 20)
Description/Summary of the Product
A surface mount device is the CD43 34.7uH 1A SMD Power Inductor. The core is a ferrite drum around which a wire is coiled. This inductor is RoHS compliant and contains a magnetic shield. The power inductor has a moisture sensitivity rating of 1, indicating that it is very resistant to moisture. This type of inductor features surface mounting pads.
Applications of the Product :
Ideally utilized as DC-DC converter inductors in mobile phones, MP3, PDAs, HDDs, DSC/DVCs, and other electronic devices.
Product Features
Ferrite drum center composition is one of the features.
The size is little.
Magnetic protection.
Resistant against moisture.
Surface installation.
Compliant with RoHS.
Specifications:
Inductance(uH) 4.7
SMD/SMT mounting type
Ferrite Core Material
Tolerance (20%) 20
1.62 current rating (mA)
At 20?C, DC Resistance (DCR)(m) = 108.7
7.96 MHz frequency
Temperature range (?C): -40 to 100
4.3 mm in length
4 mm in width
3.2 mm in height
1 gram?weight (approx.)
* Item photos are intended for illustration reasons and may fluctuate from the actual product.
