ADC0838CIWM

The ADC0831 series are 8-bit successive
Address Logic approximation A/D converters with a serial I/O and
configurable input multiplexers with up to 8 channels. ? Shunt Regulator Allows Operation with High
The serial I/O is configured to comply with the TI Voltage Supplies MICROWIRE serial data exchange standard for easy
? 0V to 5V Input Range with Single 5V Power interface to the COPS family of processors, and can
Supply interface with standard shift registers or ?Ps.
? Remote Operation with Serial Digital Data Link The 2-, 4- or 8-channel multiplexers are software
? TTL/MOS Input/Output Compatible configured for single-ended or differential inputs as
? 0.3 well as channel assignment. in. Standard Width, 8-, 14- or 20-Pin PDIP
Package The differential analog voltage input allows increasing
? 20 Pin PLCC Package (ADC0838-N Only) the common-mode rejection and offsetting the analog
zero input voltage value. In addition, the voltage ? SOIC Package
reference input can be adjusted to allow encoding
any smaller analog voltage span to the full 8 bits of
resolution
