TNY288PG IC – Power Integrations Off Line Switcher IC
TNY288PG is also belongs to TinySwitch-4 Family from the manufacturer "Power Integrations". It is Energy-Efficient, Off-Line Switcher with Line Compensated Overload Power. It comes with following features:-
- Lowest System Cost with Enhanced Flexibility
- 725 V rated MOSFET
- Increases BV de-rating margin
- Line compensated overload power ? no additional components
- Dramatically reduces max overload variation over universal input voltage range
- ?5% turn on UV threshold: line voltage sense with single external resistor
- Simple ON/OFF control, no loop compensation needed
- Selectable current limit through BP/M capacitor value
- Higher current limit extends peak power or, in open frame applications, maximum continuous power
- Lower current limit improves efficiency in enclosed adapters/ chargers
- Allows optimum TinySwitch?-4 choice by swapping devices with no other circuit redesign
- Tight I2 f parameter tolerance reduces system cost
- Maximizes MOSFET and magnetics utilization
- ON-time extension ? extends low-line regulation range/hold-up time to reduce input bulk capacitance
- Self-biased: no bias winding or bias components
- Frequency jittering reduces EMI filter costs
- Pin-out simplifies heat sinking to the PCB
- SOURCE pins are electrically quiet for low EMI
